Nature Water Blowing Filling Capping Combiblock Full Automatic High Speed

Nature Water Blowing Filling Capping Combiblock Full Automatic High Speed

    • Nature Water Blowing Filling Capping Combiblock Full Automatic High Speed
    • Nature Water Blowing Filling Capping Combiblock Full Automatic High Speed
    • Nature Water Blowing Filling Capping Combiblock Full Automatic High Speed
  • Nature Water Blowing Filling Capping Combiblock Full Automatic High Speed

    Product Details:

    Place of Origin: Zhangjiagang, Jiangsu, China
    Brand Name: Sunswell
    Certification: CE
    Model Number: BFC

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: USD500,000~2,000,000/SET
    Packaging Details: PE film with carton box packaging
    Delivery Time: 90~120 working days
    Supply Ability: 10sets/season
    Contact Now
    Detailed Product Description
    Product: Drinking Water Package: PET Bottles
    Filling Temperature: Ambient Temperature Filling Technology: Gravity Filling, Volumetric Filling
    Production Capacity: 12,000BPH - 40,000BPH Guarantee: 2 Years
    Cap: Plastic Cap Service: Engineers Able To Come To Client Factory For Machine Installation And Commissioning

    Nature Water Blowing Filling Capping Combiblock Full Automatic High Speed







    Sunswell Blowing Filling capping combiblock for bottled water in PET bottles . The blow-filling and sealing machine takes 36,000 bottles/hour (500ml) waterline as an example. Compared with the traditional split technology, it can save more than 30% of water and save more than 15% of electricity, save more than 60% of the site, and save equipment investment. More than 20%, saving operating costs of more than 15%.





    Capacity: 12,000 – 40,000BPH (500ml)



    Features



    Rotary Blow Molding Machine

    1. Horizontal heating chain drive system
    • Use high-strength brass processing to extend the service life
    • Large caliber cooling mouth, to ensure that the preform neck not heated, with effective protection of preform thread



    1. Efficient energy-saving preform heating system
    2. Patented blowing nozzle unit for stable preform



    Nature Water Blowing Filling Capping Combiblock Full Automatic High Speed

    1. Fast mold changing unit (6-screw design)
    1. H-type steel frame, reducing vibration, more stable
    2. High accurate filtration system and High pressure air recycling system
    • High-pressure air recovery system can save 30% of air, in addition, the extra gas leads to other machines.
    • High-pressure filtration system accuracy of 0.001ppmw, greatly extend the service life of pneumatic components.



    1. High speed & energy saving blowing system
    • Integrated brake system with slewing ring, more reliable and stable.
    1. Reliable electrical control
    • Through the teleservice remote monitoring system, real-time recording of any operation of the field device or shutdown information, through the analysis of software real-time analysis of equipment operating status.
    • Safety relay equipped
    1. Air conditioning and Anti-condensation System on electrical cabinet
    1. Ion air blowing



      Gravity Filling Machine



    Nature Water Blowing Filling Capping Combiblock Full Automatic High Speed

    1. Filling valves and tank are made of stainless steel SUS304.
    2. Large flat bearing with teeth, stable and reliable performance.
    3. Gravity filling.
    4. Ring shape tank with float ball level control.
    5. High speed and high accuracy filling valve with 200ml/s flowing speed
    6. Filling valve equips dummy cup and can do CIP circularly.
    7. With rotary spray ball in tank to ensure cleaning effect.
    8. Lift by pneumatic cylinders.



    Vacuum pump for filling level regulation



    Capping Machine



    1. Magnetic constant torque capping head ensures stability and controls defective rate of capping less than 0.2%.
    2. Cap dropping rail equips a group of photoelectrical switch for reverse cap detecting. When lack of cap, machine will be stopped automatically.
    3. Bottle infeed detecting switch works with the pneumatic cylinder on cap starwheel to avoid feeding cap on no-bottle condition.



    Equipment Structure

    NO. Model Capacity(based on 500ml) Remark
    1 8-32-8 15,000bph
    2 10-40-10 18,000bph
    3 12-40-15 22,000bph
    4 14-40-15 24,000bph
    5 16-50-18 30,000bph
