500ML Bottled Water Filling Machines For Mineral Water And Sparkling Water

China 500ML Bottled Water Filling Machines For Mineral Water And Sparkling Water supplier

Large Image :  500ML Bottled Water Filling Machines For Mineral Water And Sparkling Water

Product Details:

Place of Origin: China
Brand Name: Sunswell
Certification: CE, ISO, SGS, UL
Model Number: XGFH40-40-10

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Seaworthy Wooden Case
Delivery Time: 30 days
Payment Terms: T/T, L/C
Supply Ability: 100 sets per year
Contact Now
Detailed Product Description
Product Name: Automatic Packing Filling Machines Capacity: 18,000BPH
Filling Heads: 40 Rinsing Heads: 40
Capping Heads: 10 Application: Still Water, Pure Water...



500ml Bottle Water Filling Machines For Mineral Water And Sparkling Water

5.5kw 500ml, bottle mineral water, sparkling water automatic packing filling Machines,XGFH40-40-10

Qucik Detail:

1. 18000BPH capacity
2. Filling heads 40
3. For water bottles and jars
4. 3-in-1
5. Full automatic
6. Outline 4300×2930×2750mm





Specifications:



Model

CGF40-40-10

Rinsing heads

40

Filling heads

40

Capping heads

10

Capability

18,000BPH (500ml)

Total power

5.5kw

Outline

4300×2930×2750mm

Weight

7800kg





Description:



The water line is composed of separate rinsing, filling and capping units. It is innovated and designed in the requirement of still pure water and mineral water in big jars, on the bases of introducing, digesting and absorbing advanced technology from Germany and Italy.





Applications:



Still water, pure water, RO water, mineral water, sparkling water, etc. in 3L, 4L, 5L, 6L, 8L, 10L bottles and jars.





Competitive Advantage:



Main features



Rinsing Machine



Spring cramps are used in the bottle washing process. The empty bottles can be turned over 180° along the conveying rail. There are two times of internal and external washing, the efficiency of bottle washing is high.

Rinsing machine adopts our company original overturn and double-opened bottle clip. Bottle clip lock the bottleneck, the material of bottle clip is SUS304, which is hygienic and durable.
Bottle clip equipped with efficient spray on nozzle. The extrusive droplet with the angle 15° ensures to wash all side of the bottle, and can save the water.





Filling Machine



The design of filling structure is reasonable and hygiene dead angle, the run of equipment is stable, it can control the material from the bottleneck, the control accuracy is within ±2mm.
The filling valve material is SUS304
The filling system has liquid level automatic control.
Filling valve lift is controlled by the valve elevator, after filling valve contact the bottleneck, it starts to fill.
Bottle is conveying by the wheel in the filling part.





Screw Capping Machine



Screw capping machine is most precision part in the machine, which has a big influence to the goods stability and defective rate. Our screw capping has following feature.
1) Our company import of advanced technology of screw capping, improve the stability and reliability of the screw capping machine. The magnetic torque is used for screw capping. The power of screw capping can be adjusted without steps. The power of the screw capping can also be fixed, and the caps will not be damaged, the capping is reliable.
2) In the screw capping part, installed photoelectricity control, when it has no cap or the cap is bad, the machine will stop automatically.




Main Specification



Touch screen:                        Thinget

PLC program controller:         Mitsubishi

Inverter:                                  Mitsubishi

Photoelectrical controller:       Omron

Proximity switch:                      Omron

Other electrical components:  Schneider

Pneumatic component:            Airtac

Pump:                                      Nanfang

Main motor:                             Siemens


500ML Bottled Water Filling Machines For Mineral Water And Sparkling Water
