Automatic Sleeve And Shrink Labeling Machine (Shrink Sleeve for plastic square Bottles)

China Automatic Sleeve And Shrink Labeling Machine (Shrink Sleeve for plastic square Bottles) supplier

Large Image :  Automatic Sleeve And Shrink Labeling Machine (Shrink Sleeve for plastic square Bottles)

Product Details:

Place of Origin: China
Brand Name: Sunswell
Certification: CE, ISO, SGS, UL
Model Number: TB-150

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Seaworthy Wooden Case
Delivery Time: 30 days
Payment Terms: T/T, L/C
Supply Ability: 100 sets per year
Detailed Product Description

Automatic Sleeve And Shrink Labeling Machine (Shrink Sleeve for plastic square Bottles)



Container forms have become diverse and labels are now used for many types of containers such as plastic, glass, or metallic ones. When using labels, illustrations and logos are printed on the reverse side of a film. Labels are very effective for enhancing a products appeal, since the whole label can be used to display the design.



  • Food and Beverage (Sauces, Spread, Prepared meal, Snacks, Soft drinks, Fruit juices, Water, Alcoholic drinks, etc.)
  • Dairy (Milk-based drink, Yogurt drink, Yogurt Cup, Coffee creamer, Ice cream, etc.)
  • Nutrition product/Supplement (Baby food, Healthy foods, etc.)
  • Home care (Laundry, Fabric care, Detergent, Cleaning products, etc.)
  • Personal Care (Hair care, Soap and Bath products, Oral care, Skin care, Cosmetics, etc.)



  • TB-150 Sleeve Labeler Configurations:
  • PLC controller: Mitsubishi or Omron
  • Stepping motor: Taida
  • Step drivers: PANASONIC
  • Transducer: Japan KEYENCE
  • Touch screen: Taiwan Weinview


TB-150 Label Sleever Technical Parameters:

  • Size: 1500L*800W*2000H(mm)
  • 2 meters conveyor belt include
  • Gross weight: about 300KG
  • Bottle diameter: 25-125mm(max)
  • Bottle Height: 15-320mm
  • Bottle type: square bottle
  • Label length: 30-150mm(max)
  • Label thickness: 0.035-0.08mm
  • Paper pipe interior span: 3-10
  • Machine speed: 100BPM (subject to label length)
  • Power: AC 3¢380V
  • Consumed power: 2KW
  • Bottle type or big-and-small different, must change the center guide or infeed worm
  • The label-casing machine controls the power of the conveyer belt in the machine


RSS-1500 Steam Shrinker Technical Parameters:

  • Size:1500L*570W*900-1600H(mm)
  • Power: AC 3¢380
  • steam consumed capacity: 20-100 KG/H
  • steam pressure: 0.15-0.4MPa
  • Fan-power: 0.45-0.75KW


DZFZ24-0.4 Steam Generator Technological Parameter

  • Power rating: 24 KW.
  • Power: 380V
  • Rating working pressure: 0.4Mpa
  • Saturation steam temperature: 152 degree C
  • Rating evaporation capacity: 22Kg/h
  • Main size: 450L*550W*1300H (mm)
  • When the machine water scarcity then the equipment will be Automatic add water; The alarm system will be make the voice and light the alarm lamp.



  • Full stainless steel protective of main engine the machine is fully waterproof and stainless;
  • Adjustable blade base: Unique cut off, double blade for long using life
  • Positioning center guiding pole: stable label guiding and delivering;
  • Screw rod of separate bottle: stable transportation of bottles;
  • Label brushing set: more accuracy of label-casing precision;
  • Label control sensor shelf: original creation tail surface and sensor are combined to improve the precision of cutting the material.
  • Human touch screen: Auto Show cause of the malfunction, operating more humane
  • Touch-screen: operation humanization
