Industrial Continuous Ink Jet Printer Can Print Text / Number / Serial No / Image For Cable

Industrial Continuous Ink Jet Printer Can Print Text / Number / Serial No / Image For Cable

    • Industrial Continuous Ink Jet Printer Can Print Text / Number / Serial No / Image For Cable
    • Industrial Continuous Ink Jet Printer Can Print Text / Number / Serial No / Image For Cable
  • Industrial Continuous Ink Jet Printer Can Print Text / Number / Serial No / Image For Cable

    Product Details:

    Place of Origin: China
    Brand Name: Sunswell
    Certification: CE, ISO, SGS, UL
    Model Number: Y Series

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiable
    Packaging Details: Seaworthy Wooden Case
    Delivery Time: 30 days
    Payment Terms: T/T, L/C
    Supply Ability: 100 sets per year
    Contact Now
    Detailed Product Description

    IndustrIndustrial Continuous Ink Jet Printer Can Print Text / Number / Serial No / Image For Cableial continuous ink jet printer can print text, number, serial No, Image for cable



    Y-series continuous ink jet printer can print clearly Chinese and English characters, text, number, date, validity date, serial No, Image. On varies materially surfaces with high speed, suitable for beverage, food, brewery, pharmaceutical, chemical, construction material, cable and wire, electronics, tobacco and many other industries.


    Specifications:

    • Printing line: 1-5lines (1-4lines in Chinese)
    • Printing speed: 2m/s (5*7 single line)
    • Printing mode: Auto, Photocell, Encoder, Length Counter.
    • Printing times: Once or many times after sense once. (photocell once)
    • Digital Matrix: 4×7, 5×5, 5×7, 7×9, 6×12, 8×16, 9×16, 12×16, 16×28, 8×7
    • Character Matrix: 4×7, 5×5, 5×7, 7×9, 6×12, 8×16, 9×16, 12×16, 16×28, 8×7
    • Chinese Matrix: 12×12, 16×16, 16×16, 24×24
    • Editing Matrix: Reverse, Inverse, Combine, Multiple Font, Bold (within 36 dots)
    • Image: Any image within 36 dots
    • USB Port : Download/save text or image
    • Capability: Printing message 40 pieces, Image message 20 pieces
    • Length: 5000 dots per message
    • Consumption: 500ml produces 60 million dots
    • Length counting: Mark after any length interval
    • Power supply: AC220V±20% 50Hz 150VA
    • Umbilical Cord: 2.0m (or make to order)
    • Weight: 24Kg
    • Dimension: 370*270*580mm


    Applications:

    Print clearly Chinese and English characters, text, number, date, validity date, serial No, Image. On varies materially surfaces with high speed, suitable for beverage, food, brewery, pharmaceutical, chemical, construction material, cable and wire, electronics, tobacco and many other industries.



    Competitive Advantage:

    Summarize as lactiferous particle moves in electric field. Ink becomes ink stream by the force of pump, and flows into print head by controlling of solenoid. In print head, electric pulse generates vibration and makes ink stream into ink drop. Crystal vibrates 70000 times per second and makes 70000 ink drops per second.

    The vibration is fast and steady, hence it can produce continuous ink drop. Each drop has a certain distance to another, and is charged by negative electricity. The amount of negative electricity decides the angle the ink drop will deflexed. In this way, ink drops form a character.

    Ink drops with negative electricity go through defluxion board with steady positive and negative high voltage, and defluxion board forms a strong electric field to ink drops with lots of negative electricity, hence the ink drops are pushed to a place with higher positive voltage. Those ink drops with less electricity are pushed to lower position. Those ink drops without any electricity will not deflexed and go into gutter, returning to ink tank for reusing.

    To print a character of 5×7 matrix, we need 5 rows vertically, and 7 dots in one row. Inkjet printer can print letters, numbers, and image, ect.
