Pure Mineral Barrel 5 Gallon Water Filling Machine High Degree Of Automation

Pure Mineral Barrel 5 Gallon Water Filling Machine High Degree Of Automation

    • Pure Mineral Barrel 5 Gallon Water Filling Machine High Degree Of Automation
    • Pure Mineral Barrel 5 Gallon Water Filling Machine High Degree Of Automation
  • Pure Mineral Barrel 5 Gallon Water Filling Machine High Degree Of Automation

    Product Details:

    Place of Origin: China
    Brand Name: Sunswell
    Certification: CE, ISO, SGS, UL
    Model Number: TGX

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiable
    Packaging Details: Seaworthy Wooden Case
    Delivery Time: 30 days
    Payment Terms: T/T, L/C
    Supply Ability: 100 sets per year
    Contact Now
    Detailed Product Description

    Automatic Pure Mineral Barrel 5 gallon water filling machine with good price

    Desciption of Machine



    (1) This filling line specially produces 3&5 gallons barreled drinking water.

    (2)This series barreled filling production line integrates bottle washer, filler and sealer into one unit.

    (3) In order to achieve the purpose of washing and sterilizing, bottle washer adopts multiple liquid injections washing and disinfectant spray, and washing solution can be used circularly. The sealer can seal bottle caps automatically.

    (4) This filling line equips with water spraying device to sterilize caps of bottles in order to ensure those caps are aseptic and healthy.

    (5) This line also can automatically carry out bottle washing, sterilizing, filling, capping, counting and products discharging.

    (6) It has features of complete functional, novel design, and high degree of automation. It is a new kind of barreled water auto-producing line, which integrates mechanism, electricity and pneumatics technologies together.

    Specifications:

    Model TGX-
    120
    TGX-
    300
    TGX-
    450
    TGX-
    600
    TGX-
    900
    TGX-
    1200
    Filling heads 1 2 3 4 6 8
    Volume(L) 18.9 18.9 18.9 18.9 18.9 18.9
    Barrel size(mm) 270*490 270*490 270*490 270*490 270*490 270*490
    Capacity(b/n) 120 200 300 450 900 1200
    Gas pressure(Mpa) 0.4-0.6 0.4-0.6 0.4-0.6 0.4-0.6 0.6 0.6
    Gas consumption(m*3/min) 0.37 0.37 0.6 0.8 1.5 1.8
    Moto power(kw) 1.38 1.75 3.8 3.8 9.75 13.5
    Rated voltage(v) 380V/
    50HZ
    380V/
    50HZ
    380V/
    50HZ
    380V/
    50HZ
    380V/
    50HZ
    380V/
    50HZ
    Weight(kg) 680 800 1500 2100 3500


    4500





    Pure Mineral Barrel 5 Gallon Water Filling Machine High Degree Of Automation


    Pure Mineral Barrel 5 Gallon Water Filling Machine High Degree Of Automation

    Pure Mineral Barrel 5 Gallon Water Filling Machine High Degree Of Automation

    Pure Mineral Barrel 5 Gallon Water Filling Machine High Degree Of Automation
    Pure Mineral Barrel 5 Gallon Water Filling Machine High Degree Of Automation
