Automatic Bottle Labeling Machine For OPP Hot Melt Glue Label Sticker

Automatic Bottle Labeling Machine For OPP Hot Melt Glue Label Sticker

    • Automatic Bottle Labeling Machine For OPP Hot Melt Glue Label Sticker
    • Automatic Bottle Labeling Machine For OPP Hot Melt Glue Label Sticker
    • Automatic Bottle Labeling Machine For OPP Hot Melt Glue Label Sticker
    • Automatic Bottle Labeling Machine For OPP Hot Melt Glue Label Sticker
  • Automatic Bottle Labeling Machine For OPP Hot Melt Glue Label Sticker

    Product Details:

    Place of Origin: Jiangsu, China
    Brand Name: Sunswell
    Certification: CE SGS
    Model Number: TB

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiable
    Packaging Details: Wooden case
    Delivery Time: 60 days after receiving down payment
    Payment Terms: L/C, T/T
    Supply Ability: 10 sets/month
    Contact Now
    Detailed Product Description
    Product Name: Hot Melt Glue Labeling Machine Voltage: 220V/380V/Customized
    Automatic Grade: Full Automatic Condition: New
    Driven Type: Electric Type: Labeling Machine
    Packaging Type: Plastic Application: Food,Beverage
    After-sales Service Provided: Online Support,Engineers Available To Service Machinery Overseas Packaging Material: Wooden Case
    Certification: CE, SGS Warranty: 1 Year
    Function: Labeling Material: SUS304

    Automatic Rotary Bottle OPP Hot Melt Glue Label Sticker Bottle OPP BOPP Roll-Feed Labeler Labeling Packing Machine



    1. General description


    BOPP labeling machineis widely suitable for different material of container and label. The label cost is comparatiely lower, it can meet the requirements of those users who have diverse kinds of the containers. It is the most economical models in cost to make mass production and intergrated operating. The equipment has massively used modularization design concept to make it easy and simple for users to change the bottles. Whether from the replacement of star wheel, guide plate or manual speed adjustment to automatic speed control, for example changing the label is only needed to change the program, the products concept that the equipment is used for users and considered for users is embodied in everywhere.

    2. Details of each equipment

    Characteristics
    1. The container is located by the plate of up pressure and down holding, the container can be accurately positioned in various locations.
    2. Roller gluing, it is glued on the head and tail of the label which decrease the dosage of the glue and makes the glue marks in equality and nice appearance.
    3. It is simple and quick to change configuration component different containers and labels.
    4. The label station is one for usage one for storage.
    Hot melt glue machine for plastic pet bottle
    5. Exposed surface is used anti-acid/alkali stainless steel wrapped, the unstainless steel material has been strictly dealt with. For example using oxidation, spraying plastic and painting technique, avoiding the pollution of corrosive, easy to clean and maintain.
    6. The equipment operation panel of is adopted the LCD touching screen man-machine conversaton. The operation can know the equipments' all kinds of operation parameter at any time, such as speed, production capacity and the temperature of gluewater.
    7. It is adopted automatic helicoid conveying bottle device which has large operation space. The container can complete the adjustment of multi gesture at one time. The device of adjusting brush plate is very simple.
    8. Focused oil supplying system which is easy to observe and operate.



    Technical parameters:



    Power supply Three-phase 380V 50 Hz 8000W
    The total length of equipment 3000mm(conveyor length 3000mm or can be regulate base on your product lines)
    Equipment width 2000mm
    Conveyor speed 35m/min (the speed of the transmission lines can be adjusted according to actual production)
    The method of speed adjustment uninterrupted - adjust rate
    The largest Speed of labels feed maximum speed of 100 meters labels / min
    The largest speed of labeling 10000 pcs/H
    Labeling accuracy ± 1mm
    Integrated Labeling accuracy ± 1mm
    Product Size: base on client supply container 2L Φ 100mm
    Maximum label width 160mm
    The maximum length of label 500mm
    The maximum diameter of label 500mm
    Paper core diameter 152 mm
    Labeling glue leading and trailing edge gluing with hot melt
    Gluing temperature 120~160C
    Type of label opp label, paper-plastic composite film label, paper label
    Labeling workstation 12 per cycle
    The quantity of labeling mold 1 set
    Machine weight 2000 Kg



    Automatic Bottle Labeling Machine For OPP Hot Melt Glue Label Sticker



    Automatic Bottle Labeling Machine For OPP Hot Melt Glue Label Sticker
