Sunswell Machinery Co., Ltd.
Bottling machines for water, juice, carbonated drinks, milk and oil with 12 years of global market experience and more than 50 countries presence.
| Place of Origin: | Zhangjiagang,China |
|---|---|
| Brand Name: | Sunswell |
| Certification: | CE, ISO, SGS |
| Model Number: | MB-10 |
| Minimum Order Quantity: | 1 set |
| Price: | Negotiable |
| Packaging Details: | Export Standard Seaworthy Wooden Case |
| Delivery Time: | 30 days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100 sets per year |
| Voltage: | Customized | Application: | Food,Beverage,Commodity |
|---|---|---|---|
| Function: | PE Film Packaging Machine | Packing Material: | PVC POF PP PE |
| Name: | Pallet Wrapping Equipment Shrink Film Packaging Machine | Usage: | Pack The Product With Shrinking Film |
| Warranty: | 12 Months | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Highlight: | case packing machine,film packing machine |
||
Fully Automatic Pallet Wrapping Machine With CE / ISO / SGS Certificate
Applications:
Specifications:
|
Model |
MB-10 |
|
Packing form |
bottles and cans |
|
Packing speed |
10 packs/min |
|
Applicable container shape |
circular container, square container |
|
Total power charge |
19kw three-phase-five-line 380v/50Hz |
|
Machine size |
L×W×H=6500×3200×2100mm (Include 1meter no-power rear roller frame) |
|
Operating air pressure |
0.6~0.8Mpa |
|
Air consumption |
0.4stere/min |
|
Conveyor belt extreme breadth |
304mm |
|
Conveyor height |
according to client line (adjustable scope 150mm) |
Main performance features
Main parts
|
No. |
Name |
Brand |
Region |
Remarks |
|
1 |
Pneumatic Cylinder |
Chanto |
Taiwan |
|
|
2 |
Pneumatic Components |
Airtac |
Taiwan |
|
|
3 |
PLC |
Omron |
Japan |
|
|
4 |
Button |
Tayee |
China |
|
|
5 |
Inverter |
Schneider |
France |
|
|
6 |
Relay |
Schneider |
France |
|
|
7 |
Contactor |
Schneider |
France |
|
|
8 |
Solid Relay |
Crydom |
France |
|
|
9 |
Teflon Belt |
Kaiyao |
China |
Imported material |
|
10 |
Reducer |
Halei |
China |
|
|
11 |
Photoelectric Switch |
Autonics |
Korea |
|
|
12 |
Proximity Switch |
Autonics |
Korea |
|
|
13 |
Steel Sheet |
Baosteel |
China |
Cold-rolled (1.5-2.5mm) |
|
14 |
Chain Plate |
Tuoxin |
China |
POM |
