CE Automatic 5 Gallon Water Filling Machine Mineral Drink Water Barrel Packaging

CE Automatic 5 Gallon Water Filling Machine Mineral Drink Water Barrel Packaging

    • CE Automatic 5 Gallon Water Filling Machine Mineral Drink Water Barrel Packaging
    • CE Automatic 5 Gallon Water Filling Machine Mineral Drink Water Barrel Packaging
  • CE Automatic 5 Gallon Water Filling Machine Mineral Drink Water Barrel Packaging

    Product Details:

    Place of Origin: China
    Brand Name: Sunwell
    Certification: CE,SGS,ISO
    Model Number: SUNSWELL

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Packaging Details: Standard export wooden case
    Delivery Time: 45days
    Payment Terms: L/C, T/T
    Supply Ability: 100sets per year
    Contact Now
    Detailed Product Description
    Processing Types: Gravity Pressure Filling,Mineral Water Or Pure Water,Automatic Bottle Filling Sealing Machine,Spring Water Automatic Grade: Automatic
    Driven Type: Electric,Pneumatic Voltage: Can Be Designed
    Material: Stainless Steel 304/316 Filling Material: Mineral Water,pure Water,Pure/Mineral Water
    After-sales Service Provided: Engineers Available To Service Machinery Overseas,Online Support,Video Technical Support,Field Installation,Free Spare Parts Warranty: 12 Months



    Automatic 5 Gallon Mineral Drink Water Barrel Filling Packaging Machine



    Product Description of 5 gallon filling and packing machine:
    5 gallon water filling production line to introduce US companies production technology and crafts, the integration of Italy, France and other countries the advantages of similar products. The technical improvement of the automatic filling machine production line, advanced equipment technology, reliable performance, process science, good food hygiene conditions, high degree of production automation and easy to operate.
    The machine body all use high quality stainless steel material, other parts are also non-toxic, durable combination of materials, electrical, pneumatic system using imported components, so the equipment failure rate is low, high reliability.

    Complete Line Flow of 18.9L washer filler capper:
    ChartEmpty bottle Conveyor belt---→Caps Decapper---→ Brush External Bottle Washer ---→Automatic Bottle Loading System---→Internal Bottle Washer/ Disinfecter ---→ Rotary Filler ---→ Chain Plate Capper with caps washer---→Filled Bottle Conveyor Belt---→Lamp Checker---→Insert the caps label Sleeve Labeling Machine---→Heat Shrinking Machine---→Chain Style Bottle Lifter ( for the purpose to put on the plastic film cover) ---→Filled Bottles Conveyor Belt to the truck or stock room.

    Basic Specification of 5 gallon brewing and making machine:

    Model WFC Series
    Applicable Container 3 gallon ,5 gallon bottle
    The capacity of this machine is range from 100BPH to 2000BPH .
    Customized service includes automatic cap fuller, internal and external barrel scrubber, cap elevator and heat shrinker, etc.


    Technical Parameter of 20L water production line:

    Model WFC-100 WFC-200 WFC-300 WFC-450 WFC-600 WFC-900 WFC-1200 WFC-1500
    Rated Production(BPH) 100 200 300 450 600 900 1200 1500
    Installed capacity 1.3 1.7 3.8 3.8 7.5 9.7 13.5 16.5
    Weight(kg) 680 800 1500 2100 3000 3500 4500 5500


    Main Features of purified water rinsing filling capping machine:
    1.Machine set rinsing, filling, capping function in one.
    2.The overall use of high-quality stainless steel, corrosion-resistant, easy to clean.
    3.The main electrical components and the original airway are imported brands.
    4.Pump selection of Hangzhou South pump products (optional Grundfos).
    5.The nozzle is made with American spray technology.

    CE Automatic 5 Gallon Water Filling Machine Mineral Drink Water Barrel Packaging
