Place of Origin: | China |
---|---|
Brand Name: | Sunswell |
Certification: | CE, ISO, SGS, UL |
Model Number: | MB-20 |
Minimum Order Quantity: | 1 set |
Price: | Negotiable |
Packaging Details: | Seaworthy Wooden Case |
Delivery Time: | 30 days |
Payment Terms: | T/T, L/C |
Supply Ability: | 100 sets per year |
Highlight: | case packing machine,film packing machine |
---|
Industrial Automatic PE Film Shrink Wrapper Packaging Equipment for vinegar and soy sauce
Specifications:
Model |
MB-20 |
Packing form |
2×3, 3×4, 3×5, 4×5, 4×6 (According to bottles) |
Work power |
three-phase-five- line 380V/50~60Hz |
Working pressure |
0.6~0.8Mpa |
Shrink chamber size |
L×W×H=2400×650×450 (mm) |
Speed |
18 packs/min |
Sealing & cutting temperature |
190°C~230°C |
Shrink temperature |
200°C~280°C |
Material |
PE |
Roll of film width |
≤600mm |
Roll of film thickness |
0.06~0.12mm |
Roll of film diameter |
≤450mm |
Work noise |
≤65dB |
Total power |
35KW |
Total weight |
2500kg |
Machine size |
L×W×H=12000×1100×2100mm |
Conveyer belt max width |
541mm, Height of produce line (Adjustable range 150mm) |
Description:
MB series machine has been designed for no tray, no cardboard case, packing with low cost in the operations, it is widely used in food, beverage, chemical and office industries
Applications:
Main features
Main parts
No. |
Name |
Brand |
Region |
Remarks |
1 |
Pneumatic Cylinder |
Chanto |
Taiwan |
|
2 |
Pneumatic Components |
Airtac |
Taiwan |
|
3 |
PLC |
Omron |
Japan |
|
4 |
Button |
Tayee |
China |
|
5 |
Inverter |
Schneider |
France |
|
6 |
Relay |
Schneider |
France |
|
7 |
Contactor |
Schneider |
France |
|
8 |
Solid Relay |
Crydom |
France |
|
9 |
Teflon Belt |
Kaiyao |
China |
Imported material |
10 |
Reducer |
Halei |
China |
|
11 |
Photoelectric Switch |
Autonics |
Korea |
|
12 |
Proximity Switch |
Autonics |
Korea |
|
13 |
Steel Sheet |
Baosteel |
China |
Cold-rolled (1.5-2.5mm) |
14 |
Chain Plate |
Tuoxin |
China |
POM |
