1.5KW Full Automatic Pet Bottle Unscrambler Equipment 1.5M3 / Min Diameter Of 50 - 96mm

1.5KW Full Automatic Pet Bottle Unscrambler Equipment 1.5M3 / Min Diameter Of 50 - 96mm

1.5KW Full Automatic Pet Bottle Unscrambler Equipment 1.5M3 / Min Diameter Of 50 - 96mm

Product Details:

Place of Origin: China
Brand Name: Sunswell
Certification: CE, ISO, SGS, UL
Model Number: LP-14

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Seaworthy Wooden Case
Delivery Time: 30 days
Payment Terms: T/T, L/C
Supply Ability: 100 sets per year
Contact Now
Detailed Product Description

1.5KW Full Automatic PET Bottle  diameter of 50 - 96mm Unscrambler Equipment 1.5M3 / min



LP series bottle unscrambler is based on advanced foreign technology, according to requirements of beverage filling equipment high speed development, develop a domestic leading level bottle unscramble equipment.


Specifications:



Unscrambler

Model: LP-14

Number of working positions: 14

Capacity: 5,000BPH (5000ml)

Pressure of air supply: 0.7MPa

Air consumption: 1.5M3/ min

Applicable bottles: diameter of 50-96mm, height of 165-310mm

Power of main motor: 1.5KW

Dimension: Φ2200×2340mm (dia.×H)

Machine weight: 3200Kg



Elevator

Model: TP2

Power of motor: 0.75KW

Dimension: 5400×600×3500mm (L×W×H)



Applications:

Unscrambling and sorting PET bottles




Main characteristic

  • Main motor reducer adopts torque limit institutions, to prevent failure damaged machine.
  • Adopt hang bottle neck air conveyor, to prevent turnover when conveying.
  • The bottle unscrambler has stuck bottles detector, if bottle stuck, it will stop automatically and alarm.
  • The bottle unscrambler has no bottle detector, which used for sending work signal to the elevator, the elevator will supply bottle automatically.
  • Air conveyor has photoelectric switch, which control the start-stop of bottle unscrambler.
  • With maintenance door and mold changing door.
  • The main electrical component (transducer, PLC, photoelectric switch, relay) use Mitsubishi, Omron, Siemens and other famous brands.
  • Pneumatic circuit adopt international brand product.




Specification

  • Touch screen: Thinget
  • Inverter: Mitsubishi
  • PLC: Mitsubishi
  • Pneumatic cylinder: Airtac
  • Contactor & switch: Schneider
  • Photoelectrical switch: Autonics
  • Motor: Tekong or Siemens
