Automatic PET Bottle Unscrambler system with 18 workstations Max 18000BPH (500ml)
LP series bottle unscrambler is based on advanced foreign technology, according to requirements of beverage filling equipment high speed development, develop a domestic leading level bottle unscramble equipment.
Rated capacity: 15000BPH (500ml)
Max capacity: 18000BPH (500ml)
Air pressure: 0.7MPa
Gas consumption: 2M3/ min
bottle: diameter 50－96,height 165－310mm
Main motor power: 3KW
Elevator power: 0.75KW
Main machine overall : Φ2640×2340(diameter ×height)
Main machine weight: 4200Kg
Unscrambling and sorting PET bottles
Main motor reducer adopts torque limit institutions, to prevent failure damaged machine.
Adopt hang bottle neck air conveyor, to prevent turnover when conveying.
The bottle unscrambler has stuck bottles detector, if bottle stuck, it will stop automatically and alarm.
The bottle unscrambler has no bottle detector, which used for sending work signal to the elevator, the elevator will supply bottle automatically.
Air conveyor has photoelectric switch, which control the start-stop of bottle unscrambler.
With maintenance door and mold changing door.
The main electrical component (transducer, PLC, photoelectric switch, relay) use Mitsubishi, Omron, Siemens and other famous brands.
Pneumatic circuit adopt international brand product.
